AUSTRALIANSTANDARD OFHOTROLLEDH-SECTION STEELAS/NZS3679.1:2010
Name kg/m	Profile height (d)	Flange		Web thickness	nner arc radius (r)	Flange Height between
Name kg/m	Profile height (d)	Width	Thickness	(tw)	nner arc radius (r)	Flange Height between
	mm	(b,)mm	(t)mm	mm	mm	(d₁)mm
610 UB 125	611.6	229	19.6	11.9	14	572.4
113	607	228	17.3	11.2	14	572.4
101	602	228	14.8	10.6	14	572.4
530UB 92.4	533	209	15.6	10.2	14	501.8
82	528.2	209	13.2	9.6	14	501.8
460 UB 82.1	460.4	191	16	9.9	11.4	428.4
74.6	457.4	190	14.5	9.1	11.4	428.4
67.1	453.8	190	12.7	8.5	11.4	428.4
410 UB 59.7	406.4	178	12.8	7.8	11.4	380.8
53.7	402.6	178	10.9	7.6	11.4	380.8
360 UB 56.7	358.6	172	13	8	11.4	332.6
50.7	355.6	171	11.5	7.3	11.4	332.6
44.7	352	171	9.7	6.9	11.4	332.6
310 UB 46.2	307.2	166	11.8	6.7	11.4	283.6
40.4	304	165	10.2	6.1	11.4	283.6
32	298	149	8	5.5	13	282
250 UB 37.3	256.2	146	10.9	6.4	8.9	234.4
31.4	251.6	146	8.6	6.1	8.9	234.4
25.7	248	124	8	5	12	232
200 UB 29.8	207	134	9.6	6.3	8.9	187.6
25.4	203.2	133	7.8	5.8	8.9	187.6
22.3	201.6	133	7	5	8.9	187.6
18.2	198	99	7	4.5	11	184
180 UB 22.2	179	90	10	6	8.9	159
18.1	175	90	8	5	8.9	159
16.1	173	90	7	4.5	8.9	159
150 UB 18.0	155	75	9.5	6	8	136
14	150	75	7	5	8	136
