HOT ROLLED H-BEAM BRITISH STANDARD EN 10365:2017
Model	Meter weight kg/m		Section size/mm
Model	Meter weight kg/m		h mm	b mm	S mm	t mm	Sectional area cm²
UBP 203×203×45 44.9 200.2 205.9 9.5 9.5 57.2
UBP203×203X54		53.9	204	207.7	11.3	11.4	68.7
UBP254×254×63		63	247.1	256.6	10.6	10.7	80.2
UBP 254×254×71		71	249.7	258	12	12	90.4
UBP254X254X85		85.1	254.3	260.4	14.4	14.3	108.4
UBP305X305X79		78.9	299.3	306.4	11	11.1	100.5
UBP 305X305×88		88	301.7	307.8	12.4	12.3	112.1
UBP 305X305X95		94.9	303.7	3,087	13.3	13.3	120.9
UBP 305X305X110		110	307.9	310.7	15.3	15.4	140.1
UBP 305X305×126		126	312.3	312.9	17.5	17.6	160.6
UBP305×305×149		149	318.5	316	20.6	20.7	189.9
UBP 305X305×186		186	328.3	320.9	25.5	25.6	2369
UBP 305X305X223		223	337.9	325.7	30.3	30.4	284
UBP356×368×109		109	346.4	371	12.8	12.9	138.7
UBP 356X368X133		133	352	373.8	15.6	15.7	169.4
UBP356X368X152		152	356.4	376	17.8	17.9	193.7
UBP356X368X174		174	361.4	378.5	20.3	20.4	221.5
UBP 203×203×45		44.9	200.2	205.9	9.5	9.5	57.2
UBP 203×203X54		53.9	204	207.7	11.3	11.4	68.7
UBP254×254×63		63	247.1	256.6	10.6	10.7	802
UBP254X254X71		71	249.7	258	12	12	90.4
UBP 254X254X85		85.1	254.3	260.4	14.4	14.3	108.4
UBP 305X305X79		78.9	299.3	3064	11	11.1	100.5
UBP 305X305×88		88	301.7	307.8	12.4	12.3	112.1
UBP 305X305X95		94.9	303.7	308.7	13.3	13.3	120.9
UBP305X305X110		110	307.9	310.7	15.3	15.4	140.1
UBP 305X305×126		126	312.3	312.9	17.5	17.6	160.6
UBP 305×305×149		149	318.5	316	20.6	20.7	189.9
UBP305×305×186		186	328.3	320.9	25.5	25.6	236.9
UBP 305X305X223		223	337.9	325.7	30.3	30.4	284
UBP356X368×109		109	346.4	371	12.8	12.9	138.7
UBP 356X368×133		133	352	373.8	15.6	15.7	169.4
UBP356X368X152		152	356.4	376	17.8	17.9	193.7
UBP 356X368X174		174	361.4	378.5	20.3	20.4	221.5
UB 127X76X 13		13	127	76	4	7.6	16.5
UB 152X89X16		16	152.4	88.7	4.5	7.7	20.3
UB 178×102×19		19	177.8	101.2	4.8	7.9	24.3
UB 203×102×23		23.1	203.2	101.8	5.4	9.3	29.4
UB 203×133×25		25.1	203.2	133.2	5.7	7.8	32
UB 203×133×30		30	206.8	133.9	6.4	9.6	38.2
UB254X 102X22		22	254	101.6	5.7	6.8	28
UB254×102×25		25.2	257.2	101.9	6	8.4	32
UB254X102X28		28.3	260.4	102.2	6.3	10	36.1
UB 254×146X31		31.1	251.4	146.1	6	8.6	39.7
