HOT ROLLED STEELIBEAM GB/T 706-2016
Model	Dimension mm						Sectional area	Theoreticalweighit	Reference value
	Dimension mm						Sectional area	Theoreticalweighit	X-X		Y-Y
	h	b	d	t	r	r1	cm2	kg/m	l、,cm4 W,cm	i,cm	y,cm4W,cm³	,cm
10	100	68	4.5	7.6	#####	3.3	14.34	11.26	245 49.00	4.14	33 9.72	1.52
12	120	74	5.0	8.4	#####	3.5	17.82	13.99	436 72.70	4.95	47 12.70	1.62
12.6	126	74	5.0	8.4	7.0	3.5	18.12	14.22	488 77.50	5.20	47 12.70	1.61
14	140	80	5.5	9.1	7.5	3.8	21.52	16.89	712 102.00	5.76	64 16.10	1.73
16	160	88	6.0	9.9	8.0	4.0	26.13	20.51	1130 141.00	6.58	93 21.10	1.89
18	180	94	6.5	10.7	8.5	4.3	30.76	24.14	1660 185.00	7.36	122 26.00	2.00
20a	200	100	7.0	11.4	9.0	4.5	35.58	27.93	2370 237.00	8.15	158 31.50	2.12
20b	200	102	9.0	11.4	9.0	4.5	2958	31.07	2500 250.00	7.96	169 33.10	2.05
22a	220	110	7.5	12.3	9.5	4.8	42.13	33.07	3400 309.00	8.99	225 40.90	2.31
22b	220	112	9.5	12.3	9.5	4.8	46.53	36.52	3570 325.00	8.78	239 42.70	2.27
25a	250	116	8.0	13.0	10.0	5.0	48.54	38.10	5020 402.00	10.20	280 48.30	2.40
25b	250	118	10.0	13.0	10.0	5.0	53.54	42.03	5280 423.00	9.94	309 52.40	2.40
28a	280	122	8.5	13.7	10.5	5.3	55.40	43.49	7110 508.00	11.30	345 56.60	2.50
28b	280	124	10.5	13.7	10.5	5.3	61.00	47.89	7480 534.00	11.10	379 61.20	2.49
32a	320	130	9.5	15.0	11.5	5.8	67.16	52.72	11100 692.00	12.80	460 70.80	2.62
32b	320	132	11.5	15.0	11.5	5.8	73.56	57.74	11600 726.00	12.60	502 76.00	2.61
32c	320	134	13.5	15.0	11.5	5.8	79.96	62.77	12200 760.00	12.60	544 81.20	2.61
36a	360	136	10.0	15.8	12.0	6.0	76.48	60.04	15800 875.00	14.40	552 81.20	2.69
36b	360	138	12.0	15.8	12.0	6.0	83.68	65.69	16500 919.00	14.10	582 84.30	2.64
36c	360	140	14.0	15.8	12.0	6.0	90.88	71.34	17300 962.00	13.80	612 87.40	2.60
40a	400	142	10.5	16.5	12.5	6.3	86.11	67.60	217001090.00	15.90	660 93.20	2.77
40b	400	144	12.5	16.5	12.5	6.3	94.11	73.88	228001140.00	15.60	692 96.20	2.71
40c	400	146	14.5	16.5	12.5	6.3	102.1l	80.16	239001190.00	15.20	727 99.60	2.65
45a	450	150	11.5	18.0	13.5	6.8	102.45	80.42	322001430.00	17.70	855114.00	2.89
45b	450	152	13.5	18.0	13.5	6.8	111.45	87.49	338001500.00	17.40	894118.00	2.84
45C	450	154	13.5	18.0	13.5	6.8	112.17	88.05	353001570.00	17.10	938 122.00	2.79
50a	500	158	12.0	20.0	14.0	7.0	119.30	93.65	46500 1860.00	19.70	1120142.00	3.07
50b	500	160	14.0	20.0	14.0	7.0	129.30	101.50	486001940.00	19.40	1170146.00	3.01
50c	500	162	16.0	20.0	14.0	7.0	139.30	109.35	506002080.00	19.00	1220151.00	2.96
55a	550	166	12.5	21.0	14.5	7.3	134.19	105.34	629002290.00	21.60	1370164.00	3.19
55b	550	168	14.5	21.0	14.5	7.3	145.19	113.97	656002390.00	21.20	1420170.00	3.14
55C	550	170	16.5	21.0	14.5	7.3	156.19	122.61	68400 2490.00	20.90	1480175.00	3.08
56a	560	166	12.5	21.0	14.5	7.3	135.44	106.32	656002340.00	22.00	1370165.00	3.18
56b	560	168	14.5	21.0	14.5	7.3	146.64	115.11	685002450.00	21.60	1490174.00	3.16
56c	560	170	16.5	21.0	14.5	7.3	157.84	123.90	714002550.00	21.30	1560183.00	3.16
63a	630	176	13.0	22.0	15.0	7.5	154.66	121.41	939002980.00	24.50	1700193.00	3.31
63b	630	178	15.0	22.0	15.0	7.5	167.26	131.30	981003160.00	24.20	1810204.00	3.29
63C	630	180	17.0	22.0	15.0	7.5	179.86	141.19	10200 3300.00	23.80	1920214.00	3.27
