Hot-rolled channel steel GBT 706-2016
Phone: +8619506887039WhatsApp:+8619506887039Email: Dangchong@jiukun.vipHOT ROLLED U-CHANNEL STEEL SERIES GB/T706-2016
Model
Dimension mm
Sectional area
Theoretical weightReference value X-X Y-Y h b d t r r1 cm2 kg/m x,cm⁴ Wx,cm x,cm
y,cm4 W,cm³ i,cm10 100 48 5.3 8.5 8.5 4.2 12.74 10 198 39.7 3.95 25.6 7.8 1.41 12 120 53 5.5 9 9 4.5 15.36 12.1 346 57.7 4.75 37.4 10.2 1.56 12.6 126 53 5.5 9 9 4.5 15.69 12.3 391 62.1 4.95 38 10.2 1.57
